Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount Featured Image
  • Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount
  • Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount
  • Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount
  • Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount
  • Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount

Single-Phase Aluminum casing Motor – 1.1 kW (1.5 HP) – 4-Pole-B35 Mount

Short Description:

Zhuhong Single-Phase Asynchronous Motor
▪️TYPE:ML-90S-4
▪️MOUNTING:B35
▪️POWER: 1.1KW/1.5HP
▪️POLE:4P/1400RMP
▪️VOLTAGE:220V
▪️FREQUENCY:50HZ
▪️PROTECTION:IP55
▪️INSULATION:CLASS 155(F)

✅ The housing is made of aluminum alloy, offering corrosion resistance while remaining lightweight, making it easy to replace and install.

✅ The capacitor box is made of cast iron, making it more robust and safer than traditional plastic capacitor boxes.

✅ The stator employs advanced technology and is wound with 100% pure copper wire, helping to enhance efficiency and durability while reducing power consumption.

✅ This rotor features a high-temperature-treated steel core, ensuring the generation of a strong magnetic field, smooth operation, and a long service life.


Product Detail

Motor parts

Basic parameters

Packaging & Delivery

Product Tags

This aluminum-cased single-phase asynchronous motor features significant optimizations compared to traditional single-phase asynchronous motors. The rotor utilizes high-quality, high-strength materials, while the stator is wound with 100% copper wire over premium silicon steel laminations. Class F insulation ensures safe and stable operation, while an IP55 rating for dust and moisture protection further highlights the motor’s robust durability and performance. It is widely utilized in industrial and agricultural applications, such as water pumps, industrial fans, harvesters, and lawnmowers.

  • Previous:
  • Next:

    • 微信图片_20260428132306_1047_42

    Model NO. ML-90S-4 Number of Stator Single-Phase
    Species ML Series Three-Phase Rotor Structure Squirrel-Cage
    Casing Protection Protection Type Number of Poles 4
    Starting Mode Direct on-line Starting Certification ISO9001,CCC CE
    Colour Blue,Black,Grey Mount B35
    Coor Blue,BlackGrey Packing Carton
    Packing/Wooden Case
    Lead Time 15-25days Protection Class IP54,IP55
    Temperature -15℃~40℃ Transport Package Carton
    Packing/Wooden Case
    Trademark ZHUHONG Origin Zhejiang,China
    Package Size 37.5*20.5*25.5
    Package Gross Weight 13kg
    Lead Time 25day
